型號參數項目

適用帶寬
mm

額定吊高
h/mm

磁場強度
≈mT

勵磁功率
Kw

風機功率
Kw

驅動電機功率Kw

外型尺寸 mm

適用帶速
≤m/s

整機重量
Kg

L

W

H

 RCDF-T-6.5

T1

650

200

90

3.0

0.37

2.2

1050

710

900)

4.5

1730

T2

120

5.0

0.75

2.2

1090

750

940

1880

T3

150

8.0

1.1

2.2

1090

750

970

1950

RCDF-T-8

T1

800

250

90

5.0

0.37

2.2

1180

900

970

4.5

2400

T2

120

9.0

0.75

2.2

1180

900

1010

2650

T3

150

13.0

1.1

3.0

1180

900

1050

2780

RCDF-T-10

T1

1000

300

90

7.5

0.75

3.0

1380

1100

1080

4.5

3050

T2

120

12.5

1.1

3.0

1380

1100

1140

3780

T3

150

16.5

1.5

4.0

1380

1100

1170

4350

 RCDF-T-12

T1

1200

350

90

10.0

1.5

4.0

1600

1300

1200

4.5

4650

T2

120

14.0

1.5

4.0

1600

1300

1260

5150

T3

150

21.0

2.2

5.5

1600

1300

1300

6240

 RCDF-T-14

T1

1400

400

90

14.0

1.5

4.0

1780

1460

1300

4.5

6100

T2

120

18.0

0.75×2

5.5

1780

1460

1370

7850

T3

150

26.0

0.75×2

5.5

1780

1460

1420

8760

RCDF-T-16

T1

1600

450

90

15.0

1.5

5.5

1980

1660

1400

4.5

7600

T2

120

32.0

1.1×2

5.5

1980

1660

1460

9370

T3

150

32.0

1.5×2

7.5

1980

1660

1520

10970

 RCDF-T-18

T1

1800

500

90

19.0

1.1×2

7.5

2050

1950

1500

4.5

9870

T2

120

28.0

1.5×2

7.5

2050

1950

1600

13950

T3

150

38.0

2.2×2

11.0

2050

1950

1670

15920

 RCDF-T-20

T1

2000

550

90

24.0

1.5×2

7.5

2660

2300

1600

4.5

14400

T2

120

32.5

2.2×2

11.0

2660

2300

1670

17700

T3

150

245.0

2.2×2

11.0

2660

2300

1710

20900

RCDF-T-22

T1

2200

600

90

28.0

1.5×2

11.0

2410

2610

1700

4.5

17900

T2

120

36.0

2.2×2

11.0

2410

2610

1730

21840

T3

150

52.0

3.0×2

15.0

2410

2610

1760

25930

 RCDF-T-24

T1

2400

650

90

32.0

2.2×2

15.0

22610

2870

1800

4.5

22650

T2

120

43.0

2.2×2

15.0

2610

2870

1850

27820

T3

150

62.0

3.0×2

15.0

2610

2870

1960

32100
